Wurlitzer 206A Vibrato / Aux Output Kit

Regular price $94.99 $0.00 Unit price per

Vintage Vibe offers a kit that comes all the components needed to add vibrato and an aux output to your 206A Student Model Wurlitzer Piano!


Product Details

Description

Whats Included

Instructions

Video

Description

This kit is the missing link between your student model amp and the 200A amplifier.  It comes all the components needed to add vibrato and an aux output to your 206A Student Model Wurlitzer Piano.

Late model aux-out production started at serial #102905 (schematic #203720-S-3).  If your piano's serial number falls before this, use the EARLY set of transistors.  If your piano's serial number is later, then use the LATE set.

Replacement Transistor Pinouts May Not Match Original
See Instructions and Video Tabs for Diagrams, Transistor Pinouts and Installation Videos

NOTE:
To ensure you receive the correct components for your piano, please be certain that your piano is a 206A model and contains a 200A style amplifier before placing your order.  There is a 25% restocking fee for this product.  We do not offer instructions or technical support for this item other than what is listed here. We are not responsible for damage to the product or your unit during installation. If you are not confident in your abilities to perform this type of installation you may send the unit to us for service.

Whats Included

• Vibrato Potentiometer
• LDR
• Electrolytic Capacitors
• Transistors
• Resistors
• Trimpot
• Aux Output Assembly w/Potentiometer, Jack & Shielded Cable
• Aux Output Jack Holder
• Board Pins
• Hookup Wire
• Shrink Tubing The kit will contain two sets of TR15 and TR16 transistors marked "EARLY and "LATE".

Video

5 Part Video Installation
